- The protective thickness of the door slab
The overall thickness of door measure160 mm and comprises a solid core of special formulated therm alloy metal mix barrier material rei forcedwith anti-penetration bars encased between heavy steel press formed plates with lock case forming an integral part of the door structures. additional security has been achieved with incorporating defensive FHR harden steel alloy securing the vital parts of the locking mechanism
- Locking mechanism
Secured by UL listed three wheel combination lock with a security capability of 1, 000, 000 combination variations and Kaba Mauer UL listed president 8 levers mechanical key lock with approximate 280 000theoretical variation
- Body thickness
The safe body has an overall thickness of 100 mm and encasing monolithic barrier of fs metal mix thermo-alloy protective material the monolithic concept, being the single cast unit of consistent density .gives the safe body is strength and high protective
- Bolt work system
A series of heavy-duty mm diameter steel away full length running bolts secure the door in specially reinforced body sections ensuring maximum protection against intrusion by any mechanical tools attack. it also incorporates the impressive gyro-gearing mechanism for smooth bolt work movement and allows maximum throwing of the bolts into the cup-formed reinforced section of the body. the back is engaged with the full vertical reinforced interlocking rebate system
- Emergency re locking devices
Live & dead rocking devices will automatically activate and sites all bolts, if forcible attacks are made especially by explosive charges or mechanical tools, live rocking devices are designed for parallel protection securing mechanism while dead rocking devices are independent locks
- Digital lock (optional )
Upgradable to any ul-listed digital lock
Size 1
External: 711H x 605W X 660D
Internal: 500H x 400W x 500D
Features: 1 full-width drawer, 3 moving front bolts, 1 top moving bolts, 1 dead rocker, 1 adjustable shelf, full-length vertical rebate, 1 bottom moving bolts, 1 live rocker
Weight: 500 kgs
Size 2
External: 890H x 685W X 735D
Internal: 680H x 475W x 575D
Features: 1 full-width drawer, 4 moving front bolts, 1 top moving bolts, 1 dead rocker, 1 adjustable shelf, full-length vertical rebate, 1 bottom moving bolts, 1 live rocker
Weight: 650 kgs
Size 3
External: 1095H x 760W X 815D
Internal: 865H x 535W x 650D
Features: 1 full-width drawer, 4 moving front bolts, 1 top moving bolts, 1 dead rocker, 1 adjustable shelf, full-length vertical rebate, 1 bottom moving bolts, 1 live rocker
Weight: 820 kgs
Size 4
External: 1390H x 760W X 815D
Internal: 1180H x 535W x 650D
Features: 1 full-width drawer, 5 moving front bolts, 1 top moving bolts, 1 dead rocker, 2 adjustable shelves, full-length vertical rebate, 1 bottom moving bolts, 1 live rocker
Weight: 1220 kgs
Size 5
External: 1650H x 760W X 815D
Internal: 1430H x 535W x 650D
Features: 1 full-width drawer, 6 moving front bolts, 2 top moving bolts, 1 dead rocker, 2 adjustable shelves, full-length vertical rebate, 2 bottom moving bolts, 1 live rocker
Weight: 1315 kgs
Size 6
External: 1830H x 760W X 815D
Internal: 1610H x 535W x 650D
Features: 1 full-width drawer, 6 moving front bolts, 2 top moving bolts, 2 dead rockers, 2 adjustable shelves, full-length vertical rebate, 2 bottom moving bolts, 1 live rocker
Weight: 1600 kgs
